GEPRC TAKER H65_8S_BLS 65A 4in1 ESC – Extreme 8S High-Voltage Power

Original price was: $68.99.Current price is: $56.99.

Customer Reviews

★★★★★
★★★★★
5.0 out of 5
22 global ratings
MODEL:
H65_8S_BLS 65A 4IN1 ESC
  • 8S Power Support: Supports 3S to 8S LiPo input for extreme high-voltage flight.
  • Massive Output: 65A continuous and 75A burst current for high-demand setups.
  • G071 32-bit MCU: Powerful processor ensures stable and smooth motor synchronization.
  • Voltage Safety: Built-in TVS protective diode filters out high-voltage spikes.
  • Efficient Cooling: CNC aluminum heatsink provides superior thermal management.
  • Universal Fit: Standard 30.5×30.5mm mounting pattern for most FPV frames.

Shop GEPRC TAKER H65 8S BLS ESC. Features 65A continuous current, 3-8S LiPo support, and G071 MCU. Reliable high-power 8S performance at WYECS.

Unlock extreme potential with the GEPRC TAKER H65 8S BLS, a powerhouse designed for pilots who demand high-voltage efficiency and raw power. This 8S FPV Drone ESC is specifically engineered to handle the intense electrical loads of cinematic lifters and long-range rigs, providing native support for up to 8S LiPo batteries.

Leveraging the STM32G071 32-bit MCU, this BLHeli_S 65A ESC brings modern processing speed to the reliable BLHeli_S platform. It is fully compatible with Bluejay firmware, enabling bi-directional Dshot and high PWM frequencies for a smoother, quieter flight experience. As a heavy-duty 65A 8S 4in1 ESC, it delivers a massive 65A continuous output and a 75A burst capability, ensuring you have the "punch" needed for aggressive maneuvers.

Durability is at the core of the GEPRC TAKER 65A BLS. It features an integrated CNC aluminum heatsink for optimal heat dissipation and an onboard TVS diode to shield your sensitive electronics from high-voltage spikes. Whether you're chasing peaks or carrying professional camera gear, the TAKER H65_8S_BLS provides the stable, geek-level performance required for elite 8S missions.

Specifications

  • Input Voltage: 3-8S Lipo
  • Ammeter: Support
  • Continue Current: 65A
  • Burst Current: 70A(5 seconds)
  • Support Protocol: Dshot 150/300/600
  • Size: 42×45.7mm
  • Mounting Holes: 30.5×30.5mm, φ4mm hole becomes φ3mm after using the silicone shock-absorbing ring.
  • Weight: 14.9g
  • Target: B_X_30

Includes

1 x ESC

1 x Capacitor

1 x Flight Controller Adapter Cable

1 x XT60 Power cable

4 x Silicone anti-shake pads

SUPPORT

FAQ

Q: What is the benefit of the 9V/10V BEC on GEPRC flight controllers?+
Digital HD systems like DJI O3 or Walksnail require stable, high-current power. A dedicated 9V or 10V BEC provides cleaner power than a 5V rail and protects your video system from voltage drops during aggressive throttle maneuvers....more
View Full Article: Details >
Q: Is the TAKER H65 8S ESC compatible with smaller 4S batteries?+
Yes. The “8S” rating indicates the maximum voltage the hardware can handle. It is fully backward compatible with 3S, 4S, and 6S LiPo batteries. Using a lower voltage actually provides more hardware headroom and increases reliability....more
View Full Article: Details >
