GEPRC TAKER H65_8S_32BIT 65A 4in1 ESC – Ultimate 8S Power

Original price was: $88.99.Current price is: $78.80.

Customer Reviews

★★★★★
★★★★★
5.0 out of 5
343 global ratings
MODEL:
H65_8S_32BIT 65A 4in1 ESC
  • Powerful 65A continuous and 75A burst current.
  • Supports 3-8S LiPo for extreme high-voltage power.
  • Advanced 32-bit BLHeli_32 firmware performance.
  • Large-area heatsink for superior thermal cooling.
  • Premium MOSFETs ensure high-reliability flight.
  • Standard 30.5 x 30.5mm mounting for easy install.

Upgrade your build with the GEPRC TAKER H65 ESC. This high-performance 65A 4in1 ESC supports up to 8S LiPo, making it the perfect choice for Racing Drone Electronics that require extreme power and smooth 32-bit BLHeli_32 ESC control.

Unlock the true potential of high-voltage flight with the GEPRC TAKER H65 8S ESC. This beast is engineered for pilots pushing the boundaries of cinematic and long-range drones, serving as a dedicated 8S FPV Drone ESC that handles the most demanding power setups with ease.

Equipped with a powerful G071 32-bit MCU, this BLHeli_32 65A ESC supports a high PWM frequency of up to 128KHz. This results in an incredibly smooth throttle feel, reduced motor noise, and increased efficiency. As a robust 65A 4in1 ESC 8S, it provides a continuous 65A output and a 75A burst per channel, ensuring you have the "punch" needed for aggressive freestyle or heavy-lift missions.

The GEPRC TAKER 65A ESC is built with longevity in mind, featuring an integrated aluminum heatsink for superior thermal management and a built-in TVS protective diode to filter out voltage spikes. Whether you are chasing mountain peaks or racing at high speeds, the TAKER H65 delivers the stable, "geek-level" performance required for professional 8S builds.

Feature Specification
MCU STM32G071 (32-bit)
Continuous Current 65A
Burst Current 75A (5 Seconds)
Input Voltage 3S - 8S LiPo
Firmware BLHeli_32 (GEPRC_G071_01)
PWM Frequency 24K - 128KHz
Mounting Pattern 30.5 x 30.5mm (M4 holes)

Specifications

  • Input Voltage: 3-8S Lipo
  • Ammeter: Support
  • Continue Current:65A
  • Burst Current:70A (5 seconds)
  • Support Protocol: Dshot 150/300/600
  • Size: 42×45.7mm, hole30.5×30.5mm, φ4mm hole becomes φ3mm after using the silicone shock-absorbing ring.
  • Weight: 15.8g
  • Target: GEPRC_F4_4in1

Includes

1 x ESC

1 x Capacitor

1 x Flight Controller Adapter Cable

1 x XT60 Power cable

4 x Silicone anti-shake pads

SUPPORT

FAQ

Q: What is the benefit of the 9V/10V BEC on GEPRC flight controllers?+
Digital HD systems like DJI O3 or Walksnail require stable, high-current power. A dedicated 9V or 10V BEC provides cleaner power than a 5V rail and protects your video system from voltage drops during aggressive throttle maneuvers....more
View Full Article: Details >
Q: Is the TAKER H65 8S ESC compatible with smaller 4S batteries?+
Yes. The “8S” rating indicates the maximum voltage the hardware can handle. It is fully backward compatible with 3S, 4S, and 6S LiPo batteries. Using a lower voltage actually provides more hardware headroom and increases reliability....more
View Full Article: Details >
